UV/IR

Special Feature

Type UV&IR, Indoor, Non explosion-proof
Nominal Sensing Range 30m
Sensing Angle 100°, Cone type
Operation Temperature -20 ~ +60 ℃
Keeping Temperature -35 ~ +90 ℃
Output Signal
Relay
Fire A-contact 5A(250VAC, 28VDC)
B-contact 3A(250VDC, 28VAC)
Fault A-contact 5A(250VAC, 28VDC)
RS-485
2 steps selective sensitivity

Structure

Material Aluminum
Surface Anodizing Process
Color Silver
Weight 0.75kg
External 80mm ⅹ 78mm ⅹ 84mm, Hexahedral, Connector ½” PF

Electrical

Power Consumption 2.4W
Input Voltage DC24V(15~32V, pulsating current enable)
Current
Idle 50mA
Fire 80mA
