IR3

Special Feature

Type IR3, Indoor, Non explosion-proof
Nominal Sensing Range 50m
Sensing Angle 90°, Cone type
Operation Temperature -40 ~ +85 ℃
Keeping Temperature

-40 ~ +85 ℃

Output Signal
Relay
Fire A - contact 5A(250VAC, 28VDC)

B - contact 3A(250VDC, 28VAC)

Fault A - contact 5A(250VAC, 28VDC)
RS-485
4~20mA
2 steps selective sensitivity

Structure

Material Aluminum
Surface Anodizing Process
Color Red
Weight

0.77kg

External 89mm ⅹ 78mm ⅹ 84mm, Hexahedral, Connector ½” PF

Electrical

Power Consumption 2.4W
Input Voltage DC24V(15~32V, pulsating current enable)
Current
Idle 50mA
Fire 80mA
